IPX39 comprehensive rain test box

Category:

IPX3-9 comprehensive rain test box

Reference standard no: 1056272349424082944

As a professional equipment manufacturer, Yuexin always insists on the route of independent innovation and is committed to providing better waterproof testing solutions. The company has applied for more than 30 patent certificates and passed the national high-tech enterprise certification. The company has its own brand and has passed the GB/T29490-2013 intellectual property management system certification.

Can be customized according to customer requirements

Order Hotline:18122108955

Inquiry

Product description
parameter
Test rendering

construction scheme

Series Products

Key words:
- IPX39 comprehensive rain test box

Basic parameters
Inner box size	Approximately length 1300* depth 1300* 1300mm in height
External dimensions	Approximately length 1750* depth 3920* 1960mm in height
Turntable diameter	￠400mm
Turntable maximum load	50KG
Turntable lifting height	600-1000 mm
Turntable speed	1 -5r/min (precisely adjustable)
Turntable rotation method	Always forward / forward and reverse alternately (touch screen control)
Flow adjustment method	Automatic adjustment of flow rate with flow sensor (touch screen control)
Pressure adjustment method	Automatic pressure adjustment with pressure sensor (touch screen control)
testing time	0-999 min (touch screen control)
Total mass of equipment	about 400kg
IPX3-4-4K Part - Technical Parameters
Swing tube radius size	R600mm
R600 pendulum flow	IPX3=1.8L/min±5%；IPX4=2.6L/min±5% IPX4K=22.2L/min±5%
IPX34 water spray aperture	0.4mm
IPX4K water spray aperture	0.8mm
Spray Aperture Spacing	50mm
traffic adjustment	Flow Sensors
swing tube inner diameter	15mm
swing angle	120º (IPX3), 350º (IPX4) or (touch screen setting)
swing speed	240° back and forth 4S, 720° back and forth 12S (precise control) or (touch screen setting)
IPX5-6-6K Part - Technical Parameters
IPX5, 6K water spray aperture	6.3mm
IPX6 water spray aperture	12.5mm
IPX5-6-6K traffic	IPX5=12.5±0.625(L/min) ; IPX6=100±5（L/min）; IPX6K=75±5（L/min）
flow adjustment method	Flow Sensors
Pressure adjustment method	Pressure Sensor
Spray gun swing mode	Swing in the vertical direction, the swing height and speed are set by the touch screen
IPX9-9K Part - Technical Parameters
Nozzle Specifications	IEC60529:20123, GB/T4208-2017 standard nozzle
Spray flow	14-16L or touch screen setting
spray pressure	10MPA
Water spray pressure calibration	0.9-1.2N force value calibration system (touch screen display)
water supply temperature	0-80℃ set by touch screen
nozzle adjustment	0° vertical adjustment distance 100mm; 30°, 60° horizontal adjustment distance 200mm; 90°vertical direction is adjusted by the turntable
