720L Water Immersion Test Machine

Category:

IPX7 Water Immersion Test Chamber

Reference standard no:

Outer box dimensions: approximately 670 × 670 × 2350 mm Specimen size: ≤500 × 500 × 1800 mm Test water depth: 200 mm Tested products: underwater connectors, sensors, electric toothbrushes, and other electronic and electrical devices Material: 304 stainless steel Notable clients: Huawei, BYD, Jabil, DJI, Omron, FAW Group, Delixi Electric, and others Customization available: yes Application areas: automotive components, electronics and electrical engineering, diving equipment, lighting, and more

As a professional equipment manufacturer, Yuexin always insists on the route of independent innovation and is committed to providing better waterproof testing solutions. The company has applied for more than 30 patent certificates and passed the national high-tech enterprise certification. The company has its own brand and has passed the GB/T29490-2013 intellectual property management system certification.

Can be customized according to customer requirements

Order Hotline:18122108955

Inquiry

Product description
parameter
Test rendering

construction scheme

Series Products

Key words:
- Water immersion testing machine

Basic parameters	box size	600×600×2000mm
	overall dimensions	670×670×2350mm
	maximum water depth	2000mm
	Load capacity of the bottom of the box	≤40kg
	Recommended sample size	≤500×500×1800mm
	window width	400mm

Conditions of Use	ground load capacity	≥200Kg/㎡
	Water conditions	clear tap water
	Recommended site size	Length×width≥2000×1000mm
	other conditions	Flat ground; not recommended for use on wooden floors
