Large-scale oscillating-tube rain test apparatus
Reference standard no:
As a professional equipment manufacturer, Yuexin always insists on the route of independent innovation and is committed to providing better waterproof testing solutions. The company has applied for more than 30 patent certificates and passed the national high-tech enterprise certification. The company has its own brand and has passed the GB/T29490-2013 intellectual property management system certification.
Can be customized according to customer requirements
Order Hotline:18122108955
- Product description
- parameter
- Test rendering
- construction scheme
- Series Products
-
Key words:- Large-scale oscillating tube rain test apparatus
-
Size parameters swing tube size R1600mm swing tube inner diameter greater than 15mm Outer Dimensions (Working) 4000×3200×2800mm Spray hole size φ0.4mm Turntable height range 1750-2350mm Turntable diameter φ1000mm performance parameter flow range 0-10L/min Turntable speed 1-5r/min (precisely adjustable) Turntable bearing 50 kg swing angle ≤350° or custom setting swing speed 60°/sec or custom setting Conditions of Use voltage AC 220V power 1.0 kw Recommended site size Length×width＞4500×3700mm ground load capacity ≥200kg / m2 Water conditions Purified water is recommended; tap water is also acceptable
Construction Cases
