IPX6 test chamber, 2200 L

Category:

IPX1-2 Drip Test Chamber

IPX56 Water Spray Test Chamber

Reference standard no:

Diameter: approximately 4350 × 1450 × 1800 mm Specimen dimensions: ≤800 × 700 × 700 mm Spray distance: 2.8 meters (distance from the nozzle to the center of the turntable) Tested products: underwater connectors, sensors, LED luminaires, and other electronic and electrical components Material: 304 stainless steel Notable clients: Huawei, BYD, Jabil, DJI, Omron, FAW Group, Delixi Electric, and others Customization: available upon request Application areas: automotive components, electronics and electrical engineering, diving equipment, lighting, and more

As a professional equipment manufacturer, Yuexin always insists on the route of independent innovation and is committed to providing better waterproof testing solutions. The company has applied for more than 30 patent certificates and passed the national high-tech enterprise certification. The company has its own brand and has passed the GB/T29490-2013 intellectual property management system certification.

Can be customized according to customer requirements

Order Hotline:18122108955

Inquiry

Product description
parameter
Test rendering

construction scheme

Series Products

Key words:
- Automatic Flush Test Chamber

Size parameters	Inner box size	1180×1180×1000mm
	Overall Dimensions	4350×1450×1800mm
	Recommended sample size	≤800×700×700mm
	Turntable diameter	φ800mm
	Spray distance	2.8m

performance parameter	Flush flow	IPX5:12.5±0.625 / IPX6:100±5 （L/min）
	water spray	Circular sweeping water spray
	Turntable bearing	50kg
	control method	touch screen settings
Conditions of Use	voltage	AC 380V
	power	3.0kw
	Recommended site size	Length×width≥4800×2800mm
	Water conditions	External tap water can be connected (the random matching water pipe is 3 meters long)
