200L Ocean Simulation Depth Testing Machine

Category:

1–1000 m water depth IPX8 test chamber

Stainless steel type IPX8

IPX8 Pressure Immersion Test Machine

Reference standard no:

Diameter: approximately 400 × 1600 mm Simulated water depth: 20–500 meters Specimen dimensions: approximately 350 × 1550 mm Tested products: underwater connectors, submersible electronics, pool lights, and more Material: 304 stainless steel Notable clients: Huawei, BYD, Jabil, DJI, Omron, FAW Group, Delixi Electric, and others Customization available: yes Application areas: automotive components, electronics and electrical engineering, diving equipment, lighting, and other industries

As a professional equipment manufacturer, Yuexin always insists on the route of independent innovation and is committed to providing better waterproof testing solutions. The company has applied for more than 30 patent certificates and passed the national high-tech enterprise certification. The company has its own brand and has passed the GB/T29490-2013 intellectual property management system certification.

Can be customized according to customer requirements

Order Hotline:18122108955

Inquiry

Product description
parameter
Test rendering

construction scheme

Series Products

Key words:
- Ocean Simulation Deep-Water Pressure Testing Machine

Structural parameters	Equipment dimensions	About length 1400* width 950* height 2150mm
	Equipment size	Approximately diameter 400* height 1600mm
	Tank wall thickness	10mm
	Tank material	Stainless steel
	Flange thickness	40mm
	Flange material	Stainless steel
	equipment weight	About 350KG

Function parameter	pressure control method	Automatic control (water injection pressurization method)
	control precision	±2 meters (automatic)
	Test water depth range	20—500 meters
	Pressure adjustment range	0.2—5.0Mpa
	Safety valve discharge pressure	5.5Mpa
	Maximum ultimate pressure	6.0Mpa
	Test time setting range	0-999999 S
	protective device	Leakage switch, pressure safety valve protection, 2 mechanical pressure relief valves, manual pressure relief switch, emergency stop button
	control settings	Can set and store multiple groups of modes, and each group of modes can set 5 consecutive stages (time and pressure can be set)
Electrical parameters	Voltage	220V
	power	100W
	Tank wall thickness	10mm
